30 ARK-XS 90 PENDANT – LAMP 83

ARK-XS 90 PENDANT

Technical Specifications

  • Light Color: 3000K – 4000K – Tunable White (2700K-6500K)
  • Light Source: Single – L80 – 50,000 hours
  • Color Tolerance: Step 2-3
  • Minimum Color Rendering Index (CRI): >80
  • Body: Aluminum heat sink
  • Coating: Electrostatic powder coating and wood pattern
  • Color Options: Black, White, Grey (RAL 9005, 9016, 9006)
  • Optics: Microprismatic diffuser / Matte diffuser
  • Unified Glare Rating (UGR): UGR ≤19
  • Power Factor: >0.95
  • Control Options: On/Off – DALI – Casambi
  • Driver: External
  • Operating Voltage: 220V AC ~ 240V AC
  • Operating Frequency: 50 ~ 60 Hz
  • Electrical Protection Class: Class 1
  • IK Rating: IK 09
  • IP Rating: IP 20
  • Glow Wire Test: 850°
  • Photobiological Risk Group: RG1

Download Details

indirARK-XS 90 Pendant Technical Sheet
indirARK-XS 90 Pendant Installation Instructions
indirARK-XS 90 Pendant LDT Files

Bu ürün beton tavanda uygulanamaz.

Standart

W • lm Standart DALI L (mm)
37 W • 4476 lm L SK2632001 L SK2632041 335×625
52 W • 6282 lm L SK2632002 L SK2632042 335×625
48 W • 5968 lm L SK2632003 L SK2632043 335×915
67 W • 8376 lm L SK2632004 L SK2632044 335×915
61 W • 7460 lm L SK2632005 L SK2632045 625×915
84 W • 10470 lm L SK2632006 L SK2632046 625×915
48 W • 5968 lm L SK2632007 L SK2632047 625×625
67 W • 8376 lm L SK2632008 L SK2632048 625×625
73 W • 8952 lm L SK2632009 L SK2632049 925×925
101 W • 12564 lm L SK2632010 L SK2632050 925×925

Prizmatik

W • lm UGR≤19
Standart		 UGR≤19
DALI		 L (mm)
26 W • 3156 lm L SK2635001 L SK2635041 335×625
37 W • 4476 lm L SK2635002 L SK2635042 335×625
34 W • 4208 lm L SK2635003 L SK2635043 335×915
48 W • 5968 lm L SK2635004 L SK2635044 335×915
44 W • 5260 lm L SK2635005 L SK2635045 625×915
61 W • 7460 lm L SK2635006 L SK2635046 625×915
34 W • 4208 lm L SK2635007 L SK2635047 625×625
48 W • 5968 lm L SK2635008 L SK2635048 625×625
52 W • 6312 lm L SK2635009 L SK2635049 925×925
73 W • 8952 lm L SK2635010 L SK2635050 925×925

3000K - 4000K • 3650 - 5900 gr

cccc c

IP 20 850˚

c

  • ürünlerCasambi control
  • ürünlerTunable white - 2700K~6500K
  • ürünlerEmergency kit - 3 hours
  • ürünlerWood color
