30 ARK 90 PENDANT AND SURFACE-MOUNTED – LAMP 83

ARK 90 PENDANT AND SURFACE-MOUNTED

Technical Specifications

  • Light Color: 3000K – 4000K – Tunable White (2700K-6500K)
  • Light Source: Single – L80 – 50,000 hours
  • Color Tolerance: Step 2-3
  • Minimum Color Rendering Index (CRI): >80
  • Body: Aluminum heat sink
  • Coating: Electrostatic powder coating and wood pattern
  • Color Options: Black, White, Grey (RAL 9005, 9016, 9006)
  • Optics: Microprismatic diffuser / Matte diffuser
  • Power Factor: >0.95
  • Control Options: On/Off – DALI – Casambi
  • Driver: Internal
  • Operating Voltage: 220V AC ~ 240V AC
  • Operating Frequency: 50 ~ 60 Hz
  • Electrical Protection Class: Class 1
  • IK Rating: IK 09
  • IP Rating: IP 20
  • Glow Wire Test: 850°
  • Photobiological Risk Group: RG1

Download Details

indirARK 90 Pendant Technical Sheet
indirARK 90 Pendant Installation Instructions
indirARK 90 Pendant LDT Files

Standart

W • lm Standart DALI L (mm)
37 W • 4476 lm L SK2712001 L SK2712041 360×650
52 W • 6282 lm L SK2712002 L SK2712042 360×650
48 W • 5968 lm L SK2712003 L SK2712043 360×941
67 W • 8376 lm L SK2712004 L SK2712044 360×941
61 W • 7460 lm L SK2712005 L SK2712045 650×941
84 W • 10470 lm L SK2712006 L SK2712046 650×941
48 W • 5968 lm L SK2712007 L SK2712047 650×650
67 W • 8376 lm L SK2712008 L SK2712048 650×650
73 W • 8952 lm L SK2712009 L SK2712049 941×941
101 W • 12564 lm L SK2712010 L SK2712050 941×941

Prizmatik

W • lm UGR≤19
Standart		 UGR≤19
DALI		 L (mm)
26 W • 3156 lm L SK2715001 L SK2715041 360×650
37 W • 4476 lm L SK2715002 L SK2715042 360×650
34 W • 4208 lm L SK2715003 L SK2715043 360×941
48 W • 5968 lm L SK2715004 L SK2715044 360×941
44 W • 5260 lm L SK2715005 L SK2715045 650×941
61 W • 7460 lm L SK2715006 L SK2715046 650×941
34 W • 4208 lm L SK2715007 L SK2715047 650×650
48 W • 5968 lm L SK2715008 L SK2715048 650×650
52 W • 6312 lm L SK2715009 L SK2715049 941×941
73 W • 8952 lm L SK2715010 L SK2715050 941×941

3000K - 4000K • 4500 - 7500 gr

cccc c

IP 20 850˚

c

  • ürünlerCasambi control
  • ürünlerTunable white - 2700K~6500K
  • ürünlerEmergency kit - 3 hours
  • ürünlerWood color
